ASTM B111 UNS C12200 DHP Copper Tube for HVAC & Heat Exchanger

Détails sur le produit:

Lieu d'origine:	Chine
Nom de marque:	YUHONG
Certification:	ISO, TUV, PED etc.
Numéro de modèle:	Pour l'utilisation dans les machines à coudre

Conditions de paiement et expédition:

Quantité de commande min:	500kg
Prix:	Négociable
Détails d'emballage:	Caisse en bois contreplaqué/étui en fer/lot avec capuchon en plastique
Délai de livraison:	Cela dépend de la quantité
Conditions de paiement:	T/T, L/C à vue
Capacité d'approvisionnement:	1000 tonnes par mois

Contact

Tous les produits

Pipe sans soudure en acier inoxydable (339)

Tube sans couture d'acier inoxydable (331)

Tuyau d'acier inoxydable duplex (134)

Tube d'acier inoxydable de duplex (39)

Tubes à aiguille (167)

Tubes à nageoires (720)

échangeur de chaleur (31)

tube d'échangeur de chaleur (470)

Résistance à l'échangeur de chaleur (51)

Plaque tubulaire pour échangeur de chaleur (126)

cloison d'échangeur de chaleur (39)

Refroidisseur d'air (13)

Récipient sous pression (4)

tuyau soudé d'acier inoxydable (61)

Tube soudé d'acier inoxydable (133)

Tuyau d'alliage de nickel (276)

Tube d'alliage de nickel (104)

Tube d'alliage de cuivre (252)

Tube d'acier allié (214)

Tube titanique (21)

tube recuit lumineux (175)

Tube de chaudière (153)

montage en acier (867)

Bride en acier (666)

Autres (408)

Pièces de revêtement (9)

Description de produit détaillée

Standard:	ASTM B111 / B111M (Spécification du tube de condenseur)	Qualité d'alliage:	UNS C12200
Composition chimique%:	Cu ≥ 99,90 %, P : 0,015 % - 0,040 %	Caractère:	O61 (recuit) / H55 (étiré léger) / H80 (étiré dur)
Dimensions:	Diamètre extérieur : 6,35 mm - 101,6 mm ; POIDS : 0,5 mm - 10,0 mm	Essai de qualité:	Test par courants de Foucault à 100 % selon ASTM E243
Mettre en évidence:	ASTM B111 copper tube for HVAC , DHP copper heat exchanger tube , UNS C12200 HVAC copper tube

C12200 Phosphorus Deoxidized Copper Seamless Tube for Heat Exchanger & Refrigeration System

1. General Introduction

UNS C12200 is a high-purity phosphorus deoxidized copper (Cu-DHP), the most widely used seamless copper tube for refrigeration, HVAC, heat exchangers and fluid transmission systems. Different from ordinary pure copper, C12200 adds trace phosphorus for deoxidation, which completely eliminates hydrogen embrittlement risk (hydrogen disease) and greatly improves welding, bending and flaring performance.

All our C12200 copper tubes are produced by cold-drawn seamless technology, featuring smooth surface, precise dimensional tolerance and stable mechanical properties. The seamless structure avoids leakage risks, making it ideal for long-term operation in refrigeration, plumbing and industrial heat exchange equipment.

2. Material Performance Explanation

C12200 phosphorus deoxidized copper maintains the excellent thermal conductivity and electrical conductivity of pure copper. Its outstanding corrosion resistance ensures stable service in fresh water, refrigerant and dry gas environments, and will not easily form oxide scale to block pipelines. This material can be processed in reducing atmosphere, suitable for various cold and hot forming processes. It is the standard preferred material for air conditioning condensers, evaporators, building water pipes and petrochemical fluid pipelines worldwide.

Full Technical Specifications

Item	Technical Data
Standard	ASTM B88, ASTM B280, EN 1057
UNS Number	C12200
Main Composition	Cu+Ag ≥99.90%, P: 0.015% ~ 0.040%
Manufacturing Process	Cold Drawn Seamless
Outside Diameter Range	4.76 mm – 168 mm
Wall Thickness Range	0.4 mm – 10 mm
Length	Max 28000 mm or Customized
Density	8.94 g/cm³
Thermal Conductivity	365~385 W/(m·K)
Conductivity	88~94 %IACS
End Type	Plain End / Beveled End
Inspection	Hydraulic Test, Eddy Current Test, Visual Inspection, PMI
Certificate	EN10204 3.1, Mill Test Certificate (MTC)

Product Advantages

Excellent Welding & Processing Performance

Trace phosphorus deoxidation removes internal oxygen defects, no hydrogen embrittlement during high-temperature welding and annealing. It supports bending, flaring, stamping and other deep processing, no cracking during cold forming.
Superior Thermal & Electrical Conductivity

High thermal conductivity ensures efficient heat exchange, perfectly matching the working requirements of heat exchangers, condensers and evaporators. Stable conductivity also meets the needs of electrical connection components.
Good Corrosion Resistance

Resist oxidation, water medium corrosion and mild chemical corrosion. Long service life in plumbing, refrigeration and gas transmission pipelines, low maintenance cost.
Seamless Structure & High Safety

Cold-drawn seamless manufacturing, no weld seam weakness. Withstands medium pressure and fluid impact, effectively prevents liquid and gas leakage.
Strict Dimensional Accuracy

Precise control of outer diameter and wall thickness, consistent tolerance. Easy installation and matching with various accessories, reducing construction difficulty.
Compliant & Eco-friendly

Fully comply with RoHS, ISO and international industry standards, non-toxic and environmentally friendly, applicable for global export projects.

C12200 VS Ordinary Pure Copper C11000

Performance	C12200 (DHP Phosphorus Deoxidized Copper)	C11000 (Pure Electrolytic Copper)
Oxygen Content	Extremely low, no hydrogen embrittlement	High oxygen content, easy to crack at high temperature
Welding Performance	Excellent, dense weld without pores	General, prone to air holes after welding
Cold Bending & Flaring	Excellent, not easy to crack	Ordinary, limited deep processing
Applicable Atmosphere	Reducing atmosphere (long-term stable use)	Not suitable for high-temperature reducing environment
Recommended Scenarios	Refrigeration, plumbing, heat exchanger (preferred)	Electrical conductive parts (single conductivity demand)

Quality Control & Inspection

All C12200 seamless copper tubes will pass full strict inspections before delivery to guarantee quality:

Positive Material Identification (PMI)
Hydrostatic Pressure Leakage Test
Eddy Current Testing (ET)
Dimensional Tolerance Inspection
Visual Surface Quality Inspection
Chemical Composition & Mechanical Property Testing

Third-party inspection by SGS, BV, TUV, DNV and LR is acceptable as customers’ requirements

C12200 copper seamless tubes application:

Refrigeration & HVAC Industry

Air conditioning condenser tubes, evaporator tubes, refrigeration pipeline, heating and ventilation pipeline (core application).

Heat Exchanger Equipment

Industrial heat exchangers, cooling systems for machinery and power equipment.

Building Plumbing

Drinking water pipes, heating pipes, indoor fluid transmission pipelines for residential and commercial buildings.

Petrochemical & Fertilizer Industry

Medium and low-pressure fluid pipelines, gas transmission pipes, chemical equipment connecting pipes.

Automotive Industry

Automotive air conditioning pipes, heat dissipation components, wiring harness conductive parts.

Electrical & Electronic Industry

Conductive busbars, instrument connecting tubes, precision electronic heat dissipation parts.

FAQ

What is C12200 copper?
C12200 is UNS standard phosphorus deoxidized copper (Cu-DHP), equivalent to Chinese standard TP2. It is a high-purity copper material with low oxygen content, mainly used to produce seamless copper tubes for refrigeration and plumbing systems.
What is the difference between C12200 and C11000 copper?
C12200 contains trace phosphorus for deoxidation, no hydrogen disease, better welding and bending performance; C11000 is pure copper with higher conductivity but poor high-temperature processing performance.
Is C12200 copper tube suitable for refrigeration systems?
Yes. C12200 is the mainstream material for air conditioning and refrigeration tubes, with efficient heat conduction and reliable anti-leakage performance.
Can you provide customized sizes for C12200 copper tubes?
Yes. We support customized outer diameter, wall thickness, length, surface treatment and testing standards according to customer drawings and requirements.
What certifications do your C12200 copper tubes have?
Our products are certified by ISO, RoHS, SGS, TUV, and provide EN10204 3.1 mill test reports. Third-party inspection is supported.
