SUS304 Stainless Steel Medical Hypodermic Capillary Tube For Injection 10G-34G ISO9626

Détails sur le produit:

Lieu d'origine:	Chine
Nom de marque:	YUHONG
Certification:	ISO13485:2016
Numéro de modèle:	10g-34g

Conditions de paiement et expédition:

Quantité de commande min:	50 kg
Prix:	Négociable
Détails d'emballage:	Caisses en bois
Délai de livraison:	15 - 45 jours de travail
Conditions de paiement:	T/T, LC
Capacité d'approvisionnement:	13 milliards de pièces par an

Contact

Tous les produits

Pipe sans soudure en acier inoxydable (308)

Tube sans couture d'acier inoxydable (297)

Tuyau d'acier inoxydable duplex (132)

Tube d'acier inoxydable de duplex (33)

Tubes à aiguille (134)

Tubes à nageoires (672)

échangeur de chaleur (20)

tube d'échangeur de chaleur (443)

Résistance à l'échangeur de chaleur (40)

Plaque tubulaire pour échangeur de chaleur (117)

cloison d'échangeur de chaleur (37)

Refroidisseur d'air (9)

Récipient sous pression (4)

tuyau soudé d'acier inoxydable (58)

Tube soudé d'acier inoxydable (120)

Tuyau d'alliage de nickel (266)

Tube d'alliage de nickel (92)

Tube d'alliage de cuivre (240)

Tube d'acier allié (204)

Tube titanique (15)

tube recuit lumineux (155)

Tube de chaudière (151)

montage en acier (826)

Bride en acier (615)

Autres (401)

Pièces de revêtement (7)

Description de produit détaillée

Norme de tube capillaire:	ISO9626 : 2016 (norme médicale), ASTM A269 (norme industrielle)	Matière première du tube capillaire:	Qualité médicale SUS304
Diamètre extérieur du tube capillaire:	10g-34g	Épaisseur de paroi du tube capillaire:	RW, TW, ETW, UTW
Longueur de tube capillaire:	1M, 2M ou coupé en longueur de tube d'aiguille	Le tube capillaire se termine:	Les extrémités uniques, se terminent
Surface du tube capillaire:	Brillant	Applications de tubes capillaires:	Aiguilles médicales, cathéters médicaux, dispositifs chirurgicaux, instruments de précision, etc.
Mettre en évidence:	SUS304 stainless steel hypodermic tube , medical capillary tube for injection , ISO9626 needle tube 10G-34G

SUS304 Stainless Steel Medical Hypodermic Capillary Tube For Injection 10G-34G ISO9626

A Stainless Steel Medical Hypodermic Tube is a precision-engineered, cold-drawn, welded stainless steel tube specifically manufactured for medical and surgical applications. This medical capillary tube is made by SUS304 (AISI 304) stainless steel, which is an austenitic chromium-nickel alloy known for its excellent corrosion resistance, formability, and biocompatibility. The SUS304 medical stainless steel capillary tubes are produced to meet the stringent requirements of ISO9626:2016 international standard, which governs dimensions, tolerances, material composition, mechanical properties, and surface finish. The tube size generally ranges from 10G to 34G, and the wall thickness can be regular wall, thin wall, extra-thin wall, etc. In addition to standard tubes, we can also customize non-standard tubes based on the client’s drawings. These medical grade capillary tubes are the primary raw material for manufacturing hypodermic needles, cannula, biopsy needles, catheter mandrels, and other minimally invasive surgical instruments.

The Main Advantages Of SUS304 Medical Capillary Tubes:

Biocompatibility And Safety: SUS304 is non-toxic, non-pyrogenic, and resistant to bodily fluids, ensuring patient safety and compliance with medical regulations.
Superior Corrosion Resistance
Good Mechanical Performance: Excellent combination of high tensile strength and ductility. Allows for precise point grinding (beveling).
Exceptional Surface Finish: ultra-smooth internal and external finish. This minimizes friction during insertion, reduces patient pain, prevents clot adhesion, and ensures accurate fluid flow.
Dimensional Precision & Consistenc
Weldability And Formability

Regular Sizes:

Outer Diameter		OD Range		Inner Diameter Min.
Gauge	Norminal	Min.	Max.	RW	TW	ETW
-	0.15	-	-	-	-	-
34G	0.18	0.178	0.191	0.064	0.091	0.105
33G	0.2	0.203	0.216	0.089	0.105	0.125
32G	0.23	0.229	0.241	0.089	0.105	0.125
31G	0.25	0.254	0.267	0.114	0.125	0.146
30G	0.30	0.298	0.320	0.133	0.165	0.190
29G	0.33	0.324	0.351	0.133	0.190	0.240
28G	0.36	0.349	0.370	0.133	0.190	-
27G	0.40	0.400	0.420	0.184	0.241	-
26G	0.45	0.440	0.470	0.232	0.292	-
25G	0.50	0.500	0.530	0.232	0.292	-
24G	0.55	0.550	0.580	0.280	0.343	-
23G	0.60	0.600	0.673	0.317	0.370	0.460
22G	0.70	0.698	0.730	0.390	0.440	0.522
21G	0.80	0.800	0.830	0.490	0.547	0.610
20G	0.90	0.860	0.920	0.560	0.635	0.687
19G	1.10	1.030	1.100	0.648	0.750	0.850
18G	1.20	1.200	1.300	0.790	0.910	1.041
17G	1.40	1.400	1.510	0.950	1.156	1.244
16G	1.60	1.600	1.690	1.100	1.283	1.390
15G	1.80	1.750	1.900	1.300	1.460	1.560
14G	2.10	1.950	2.150	1.500	1.600	1.727
13G	2.40	2.300	2.500	1.700	1.956	-
12G	2.70	2.650	2.850	1.950	2.235	-
11G	3.00	2.950	3.150	2.200	2.464	-
10G	3.40	3.300	3.500	2.500	2.819	-

Applications:

A. Medical & Surgical Applications (Primary):

Hypodermic Needles: The core application for injections (subcutaneous, intramuscular, intravenous).
IV Cannulas: Peripheral venous catheters.
Biopsy Needles: For tissue sampling (e.g., core biopsy).
Specialty Needles: Spinal (epidural), orthopedic, ophthalmic, and dialysis needles.
Catheter Mandrels/Introducers: As the stiffening component for guiding flexible catheters.
Surgical Instruments: Components for laparoscopic tools, guide wires, and suture needles.
