Stainless Steel Venous Indwelling Needle Tube For Drug Administration ISO9626 SUS304

Stainless Steel Venous Indwelling Needle Tube For Drug Administration ISO9626 SUS304

  • Stainless Steel Venous Indwelling Needle Tube For Drug Administration ISO9626 SUS304
  • Stainless Steel Venous Indwelling Needle Tube For Drug Administration ISO9626 SUS304
  • Stainless Steel Venous Indwelling Needle Tube For Drug Administration ISO9626 SUS304
  • Stainless Steel Venous Indwelling Needle Tube For Drug Administration ISO9626 SUS304
Stainless Steel Venous Indwelling Needle Tube For Drug Administration ISO9626 SUS304
Détails sur le produit:
Place of Origin: China
Nom de marque: YUHONG
Certification: ISO13485: 2016
Model Number: 10G-34G
Conditions de paiement et expédition:
Minimum Order Quantity: 20 KGS
Prix: Négociable
Packaging Details: Carton Box, Plastic Box, Plywood Case
Delivery Time: 15 - 45 Workdays
Payment Terms: T/T, L/C
Supply Ability: 13 Billion pieces Per Year
Contact
Description de produit détaillée
Product Name: Indwelling Needle Material Grade: SUS304
Specification: ISO9626 Diameter Sizes: 14G/16G/18G/20G/22G/24G/26G or Customize
Length: As Client's Request Needle Point: Back Cut("V" Shape) Point/ Huber Point
Mettre en évidence:

ISO9626 Stainless Steel Needle Tube

,

Indwelling Stainless Steel Needle Tube

,

Drug Administration Stainless Needle Tube

Stainless Steel Venous Indwelling Needle Tube for Drug Administration ISO9626 SUS304



An indwelling needle tube is a type of needle tubes that remains inserted in a patient's body, which can be temporarily or permanently, for various medical purposes, such as drug administration, fluid drainage, or monitoring. The indwelling needle that is implanted in veins for a long time can avoid repeated punctures. It's also known as an indwelling catheter or a permcath. It’s the core cannula of a venous indwelling needle (IV catheter), designed for safe insertion into peripheral veins for drug infusion or blood sampling for multiple times over a period (typically 72-96 hours). The indwelling needle tubes are one of our company’s high-volume manufactured medical needle tubes. We have the most advanced auto machines for needle grinding and mature technical conditions. And our needle tubes are mainly made from medical grade stainless steel 304 grade. If clients have special requirements for needle tube sizes and needle points, we can design the medical needle tubes basing on clients’ drawings and samples.



Sizes (Gauge & Dimensions):

Gauge  Nominal Outer Diameter (mm) Nominal Inner Diameter (mm) Typical Wall Thickness (mm) Primary Use Case
14G 2.10 ± 0.01 1.75 ± 0.01 0~0.175 Rapid fluid resuscitation, trauma
16G 1.65 ± 0.01 1.35 ± 0.01 0~0.150 Surgery, rapid infusion
18G 1.27 ± 0.008 1.05 ± 0.01 0~0.110 Blood transfusion, CT contrast, adults
20G 0.90 ± 0.008 0.70 ± 0.01 0~0.100 General IV therapy (adults), some meds
22G 0.70 ± 0.008 0.50 ± 0.01 0~0.100 Pediatrics, fragile veins, slow infusions
24G 0.55 ± 0.008 0.35 ± 0.01 0~0.100 Neonates, very small / fragile veins



Different Types of Indwelling Needle Tubes:

  • Peripheral IV Catheters: The most common type, used in arms/hands.
  • Safety IV Catheters
  • Blood Collection Catheters: Used for initial draw or short-term access for multiple draws.
  • Winged Infusion Sets: Often used for short-term access or difficult veins (23G, 25G, 27G are common).



Key Features:

  • Ultra-Sharp Huber or Standard Bevel for smooth, low-trauma skin and vein penetration
  • Exceptional Surface Finish to minimizes drag and the patient’s discomfort
  • High-Precision Dimension
  • Superior Corrosion Resistance, compatible with saline, blood, and a wide range of IV medications
  • Good Rigidity, allowing controlled insertion force without bending



Applications:

  • Administration of IV fluids (saline, dextrose, etc.).
  • Administration of IV medications (antibiotics, analgesics, chemotherapy, etc.).
  • Blood product transfusion
  • Contrast media injection for diagnostic imaging
  • Intermittent or continuous infusions
  • Blood sampling



Stainless Steel Venous Indwelling Needle Tube For Drug Administration ISO9626 SUS304 0
